PV Grid Connected Cabinet
Product Overview
The PV grid connected cabinet is an intelligent power conversion device used to connect photovoltaic power stations with the public utility grid. It integrates dedicated grid-connection switches, anti-islanding protection units, power quality management modules, intelligent monitoring systems, and high-precision metering instruments.
The capacity is designed to match inverter output, and the main circuit breaker is configured with a 1.2× current redundancy margin. It supports multiple voltage levels including 220V, 380V, and 10kV depending on system power requirements. The PV grid connected cabinet strictly complies with GB/T 7251 standards and meets the grid "four-capability" integration requirements. Optional RS485 communication allows remote monitoring and dispatch control. Outdoor versions use IP65-rated enclosures made of 304 stainless steel, with CCC certification and official grid-connection compliance.
Core Product Features
- Integrated anti-islanding, anti-reverse power flow, and over/under-voltage protection to ensure safe grid connection;
- Built-in energy metering and remote monitoring functions for power dispatching and data uploading;
- Full voltage level coverage suitable for residential, commercial, and large-scale photovoltaic plants;
- Outdoor corrosion-resistant and waterproof design with high and low temperature resistance and anti-aging performance for long-term operation.
Our PV grid connected cabinet solutions are engineered to ensure stable energy conversion and safe grid interaction in photovoltaic systems.
Application Fields
- Residential distributed photovoltaic systems;
- Commercial and industrial rooftop solar systems;
- Ground-mounted large-scale solar power plants;
- Mountain photovoltaic projects;
- Island and remote area photovoltaic power supply systems.
The equipment is widely used in various solar grid-connection scenarios requiring stable and safe power integration.
Enterprise Qualification & Full-Service Advantages
The company holds CCC certification and official grid-connection approval, strictly following national and utility grid standards. Pre-sales services include system selection guidance, technical consultation, and bidding support.
During production, progress updates with photos and videos are provided in real time. After-sales service includes a 2-year warranty, grid-connection commissioning guidance, and maintenance support, ensuring full lifecycle service coverage.
Product Specifications
|
Parameter Item |
Specification Details |
|
Voltage Level |
≤8kW: 220V; 8kW–400kW: 380V; 400kW–6MW: 10kV |
|
Core Configuration |
Grid switch, anti-islanding protection, metering device, smart communication module |
|
Standards |
GB/T 7251, GB/T 14549 harmonic limit standard |
|
Protection Level |
Indoor IP30, Outdoor IP65 |
|
Cabinet Material |
Cold-rolled steel with powder coating; outdoor 304 stainless steel |
